适用材料Applicable material
颗粒、粉末、碳酸钙、滑石粉、树脂膜粉粒品、面粉、淀粉
Granules, powders, calcium carbonate, talc, resin film powder, flour, starch
特点Characteristics
1、大能力。高精度失重式送料。
2、通过更换附件可对应粉体/颗粒的供料（选配件）。
3、螺杆部的分解，组装简单，清扫容易。
4、有对应规格的耐压防爆选配件。
5、可作为前部供料装置使用。
1. great ability. High precision weight loss feeding.
2. The powder/particle supply (optional) can be matched by replacing the accessories.
3. The decomposition of the screw part is simple to assemble and easy to clean.
4. there are corresponding specifications of pressure-proof explosion-proof options.
5. can be used as a front feeding device.
规格specification
|
型号 Model |
流量范围 Flow rate range |
料斗容量 Hopper capacity |
称量 Weigh capacity |
螺杆 screw |
产品重量 Feeder weight |
电源 Power supply |
|
HF-S-5A(-MP) |
500-5000kg/h |
500L |
500kg |
单轴 Single screw |
约460(480)kg Approx460(480)kg |
AC380V 3相 (AC220V 单相) 4.5 301KVA 380V AC,3phase 220V AC,1phase 4.5(3.1)kVA 带搅拌器时： 9(7.6)KVA 380V In case with agitator9(7.6)kVA |
|
HF-S-6A(-MP) |
1000-1000kg/h |
1000L |
1000kg |
约490(510)kg Approx490(5140)kg |
||
|
HF-S-6A(-MP) |
5000-30000kg/h |
2000L |
2000kg |
约580(600)kg Approx580(600)kg |
||
|
HF-S-5A(-MP) |
500-5000kg/h |
500L |
500kg |
双轴 Twin screw |
约480(500)kg Approx480(500)kg |
|
|
HF-S-6A(-MP) |
1000-10000kg/h |
1000L |
1000kg |
约510(530)kg Approx510(530)kg |
||
|
HF-S-7A(-MP) |
5000-30000kg/h |
2000L |
2000kg |
约600(620)kg Approx600(620)kg |
（ ）内为控制模块KB-2500G一体式的数据。 Specifications in parenthesis( )are for modeis unitized with control module KB-25000G
