适用材料Applicable material
树脂颗粒、树脂粉末、碳酸钙、滑石粉、树脂膜粉粒品、玻璃纤维、碳纤维
Resin particles, resin powder, calcium carbonate, talc, resin film powder, glass fiber, carbon fiber
特点Characteristics
1、无需工具即可分解主要部件(1分钟内)
2、全量排出时的残留量很少,清扫简单。
3、占用面积小。设置容易。
4、集约化产品、重量轻。
5、螺杆与搅拌器各自单独驱动。
1. Decompose the main parts without tools (within 1 minute)
2. The residual amount is small when the whole amount is discharged, and the cleaning is simple.
3. The occupied area is small. Easy to set up.
4. Intensive products and light weight.
5. The screw and the agitator are each driven separately.
规格Specification
型号 Model |
流量范围 Flow rate range |
料斗容量 Hopper capacity |
称量 Weigh capacity |
产品重量 Feeder weight |
电源 Power supply |
HF-W-1 |
10-100kg/h |
50L |
30kg |
约65kg Approx65kg |
380VAC,3phase,0.55kVA |
HF-W-2 |
50-300kg/h |
80L |
50kg |
约85kg Approx85kg |
380VAC,3phase,0.75kVA |
HF-W-3 |
200-1000kg/h |
120L |
100kg |
约180kg Approx180kg |
380VAC,3phase,1.5kVA |
HF-W-4 |
500-3000kg/h |
200L |
200kg |
约250kg Approx250kg |
380VAC,3phase,2.2kVA |
( )内为控制模块KB-2500G一体式的数据。 Specifications in parenthesis( )are for modeis unitized with control module KB-25000G
